Trek Marlin+ 6

Trek Marlin+ 6
  • Color: Matte Keswick Green
$3,199.99
Color: Matte Keswick Green
Size: Large
Wheel Size: 29-inch
Please select options Unavailable

Details

Marlin+ 6 is an electric mountain bike that's ready to power up your trail rides without breaking the bank. It's equipped with the same fun and confident geometry as the non-electric Marlin, with the added boost of Bosch's Active Line Plus drive system. A 120mm suspension fork soaks up rocks, roots, and potholes on your ride, while 9-speed Shimano CUES is durable and reliable for wherever you roll.

Wheel size:
X-Small – Small: 27.5-inch
Medium – XX-Large: 29-inch

Frame SizeX-SmallSmallMediumLargeX-Large
Wheel Size 27.5" 27.5" 29" 29" 29"
Seat Tube (cm / in) 34.0 / 13.39 37.0 / 14.57 42.0 / 16.54 45.0 / 17.72 50.0 / 19.69
Seat Tube Angle (degress) 73.8 73.8 73.8 73.8 73.8
Effective Seat Tube Angle (degress) 74 74 74 74 74
Head Tube Length (cm / in) 9.0 / 3.54 10.0 / 3.94 10.5 / 4.13 11.5 / 4.53 13.5 / 5.31
Head Tube Angle (degress) 66.5 66.5 66.5 66.5 66.5
Top Tube Effective (cm / in) 55.1 / 21.69 58.4 / 22.99 62.0 / 24.41 65.2 / 25.67 68.2 / 26.85
Bottom Bracket Height (cm / in) 31.3 / 12.32 31.3 / 12.32 31.8 / 12.52 31.8 / 12.52 31.8 / 12.52
Bottom Bracket Drop (cm / in) 4.5 / 1.77 4.5 / 1.77 6.0 / 2.36 6.0 / 2.36 6.0 / 2.36
Chainstay Length (cm / in) 47.0 / 18.50 47.0 / 18.50 48.5 / 19.09 48.5 / 19.09 48.5 / 19.09
Fork Offset (cm / in) 4.6 / 1.81 4.6 / 1.81 4.2 / 1.65 4.2 / 1.65 4.2 / 1.65
Trail (cm / in) 11.0 / 4.33 11.0 / 4.33 11.4 / 4.49 11.4 / 4.49 11.4 / 4.49
Wheelbase (cm / in) 112.9 / 44.45 116.6 / 45.91 121.8 / 47.95 125.1 / 49.25 128.4 / 50.55
Standover (cm / in) 67.8 / 26.69 71.0 / 27.95 76.0 / 29.92 77.1 / 30.35 77.5 / 30.51
Reach (cm / in) 39.0 / 15.35 41.5 / 16.34 44.0 / 17.32 47.0 / 18.50 49.5 / 19.49
Stack (cm / in) 56.3 / 22.17 59.0 / 23.23 62.6 / 24.65 63.5 / 25.00 65.3 / 25.71
Frame SizeX-SmallSmallMediumLargeX-Large
Rider Height (cm) 145 – 155 155 – 165 165 – 177 177 – 188 188 – 195
Rider Height (in) 4'9" – 5'1" 5'1" – 5'5" 5'5" – 5'10" 5'10" – 6'2" 6'2" – 6'5"
Inseam (cm) 69 – 73 74 – 78 79 – 83 84 – 89 89 – 91
Inseam (in) 27" – 29" 29" – 31" 31" – 33" 33" – 35" 35" – 36"

Specs

Frame X-Small: Alpha Gold Aluminum, curved top tube, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle. Small - X-Large: Alpha Gold Aluminum, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle.
Fork X-Small: SR Suntour XCM 34, air spring, lockout, tapered steerer, 44mm offset, Boost110, 15mm thru axle, 100mm travel. Small - X-Large: SR Suntour XCM 34, air spring, lockout, tapered steerer, 44mm offset, Boost110, 15mm thru axle, 120mm travel.
Rims Bontrager Connection, double-wall, 32-hole, 20mm width, Presta valve
Hubs Front: Shimano TC500 alloy, centerlock, 110x15mm thru axle. Rear: Shimano TC500 alloy, centerlock, 148x12mm thru axle
Tires Front: X-Small - Small: Bontrager Montrose comp, Tubeless Ready, wire bead, 30 tpi, 27.5x2.40''. Rear: Bontrager Montrose Comp, wire bead, 30 tpi, 27.5x2.4''. Front: Medium - X-Large: Bontrager Montrose Comp, wire bead, 30 tpi, 29x2.4''. Rear: Medium - X-Large: Bontrager Montrose comp, Tubeless Ready, wire bead, 30 tpi, 29x2.40''
Crankset FSA CK-220, 165mm length
Chainrings FSA, 32T, steel
Shifters Shimano U4000, 9 speed
Rear Derailleur Shimano CUES U4000
Cassette/Freewheel Shimano LINKGLIDE LG300, 11-46, 9 speed
Chain Shimano LG500, 9/10/11 speed
Brakes Tektro HD-M275 Hydraulic Disk
Rotors Tektro, centerlock, 203mm
Handlebars X-Small - Small: Bontrager alloy, 31.8mm, 15mm rise, 720mm width. Medium - X-Large: Bontrager alloy, 31.8mm, 40mm rise, 780mm width
Tape/Grips Trek Line Comp, nylon lock-on
Stem X-Small - Small: Bontrager Comp, 31.8mm, 7 degree, 35mm length. Medium - Large: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length. X-Large: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length. XX-Large: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 70mm length
Headset Semi-integrated, loose ball bearing, 1-1/8" top, 1.5" bottom
Seatpost X-Small - Small: TranzX JD-YSI34, 100mm travel, internal routing, 31.6mm, 350mm length. Medium: TranzX JD-YSI34, 125mm travel, internal routing, 31.6mm, 405mm length. Medium/Large - X-Large: TranzX JD-YSI34, 150mm travel, internal routing, 31.6mm, 456mm length
Saddle Bontrager Verse P3, steel rails
Pedals VP-536 nylon platform
Battery Bosch CompactTube 400Wh
Controller/Display Bosch Purion 200
Charger Bosch standard 2A, 110V, smart system

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Matte Keswick Green / Large / 29-inch 197216281085 5337374 MAR331399741
